Motorola CDM1250 Service Manual

Low Band Range 3 (42–50 MHz) PCBs, Schematics, and Parts Lists Section 7: 4-89
6881091C63-F
Low Band Range 3 PCB 8485908Z05 Parts
List
Circuit
Ref
Motorola
Part No.
Description
C0101 2113740F51 CAP CHIP REEL CL1 +/-30
100
C0107 2113741F25 CAP CHIP CL2 X7R REEL
1000
C0112 2113743E26 CAP CHIP .10 UF 10%
C0121 2113743E26 CAP CHIP .10 UF 10%
C0122 2113743E26 CAP CHIP .10 UF 10%
C0131 2113740F35 CAP CHIP REEL CL1 +/-30
22
C0132 2113740F35 CAP CHIP REEL CL1 +/-30
22
C0141 2113743E26 CAP CHIP .10 UF 10%
C0151 2113741F49 CAP CHIP CL2 X7R REEL
10000
C0201 2311049A57 CAP TANT CHIP A/P 10UF
10% 16V
C0202 2311049A57 CAP TANT CHIP A/P 10UF
10% 16V
C0204 2113743E26 CAP CHIP .10 UF 10%
C0212 2311049A57 CAP TANT CHIP A/P 10UF
10% 16V
C0221 2113743E26 CAP CHIP .10 UF 10%
C0222 2113743E26 CAP CHIP .10 UF 10%
C0223 2113743E26 CAP CHIP .10 UF 10%
C0224 2113740F51 CAP CHIP REEL CL1 +/-30
100
C0225 2113743E26 CAP CHIP .10 UF 10%
C0226 2113743E26 CAP CHIP .10 UF 10%
C0228 2311049A56 CAP TAN CHIP A/P 4.7 20 10
C0231 2113743B29 CAP CHIP 1.00 UF 10% 16V
C0232 2113743E26 CAP CHIP .10 UF 10%
C0234 2113743E26 CAP CHIP .10 UF 10%
C0235 2113743E13 CER CHIP CAP .022UF
C0236 2113743E16 CAP CHIP .033 UF 10% X7R
C0241 2113743E26 CAP CHIP .10 UF 10%
C0243 2113740F51 CAP CHIP REEL CL1 +/-30
100
C0244 2113743E26 CAP CHIP .10 UF 10%
C0245 2113743E26 CAP CHIP .10 UF 10%
C0246 2113741F49 CAP CHIP CL2 X7R REEL
10000
C0251 2113743E26 CAP CHIP .10 UF 10%
C0252 2311049A07 CAP TANT CHIP 1 10 16 A/P
C0254 2113743E26 CAP CHIP .10 UF 10%
C0255 2113743E26 CAP CHIP .10 UF 10%
C0256 2113740F51 CAP CHIP REEL CL1 +/-30
100
C0261 2113743E26 CAP CHIP .10 UF 10%
C0262 2113740F49 CAP CHIP REEL CL1 +/-30
82
C0265 2113743E26 CAP CHIP .10 UF 10%
C0267 2113741F49 CAP CHIP CL2 X7R REEL
10000
C0271 2113741F49 CAP CHIP CL2 X7R REEL
10000
C0272 2113743E26 CAP CHIP .10 UF 10%
C0273 2113741F37 CAP CHIP CL2 X7R REEL
3300
C0275 2311049A99 CAP TANT CHIP 47 UF 10V
20
C0276 2113741F25 CAP CHIP CL2 X7R REEL
1000
C0277 2113741F25 CAP CHIP CL2 X7R REEL
1000
C0290 2311049C01 CAP TANT CHIP 10 UF 35V
10%
C0291 2311049C01 CAP TANT CHIP 10 UF 35V
10%
C0292 2311049C01 CAP TANT CHIP 10 UF 35V
10%
C0293 2311049C01 CAP TANT CHIP 10 UF 35V
10%
C0421 2113743N48 CAP CHIP 82.0 PF 5% COG
C0422 2113741F17 CAP CHIP CL2 X7R REEL
470
C0423 2113741F17 CAP CHIP CL2 X7R REEL
470
C0426 2113743L09 CAP CHIP 470 PF 10 X7R
C0427 2113743L09 CAP CHIP 470 PF 10 X7R
C0428 2113743N48 CAP CHIP 82.0 PF 5% COG
C0429 2113743L09 CAP CHIP 470 PF 10 X7R
C0430 2113741F17 CAP CHIP CL2 X7R REEL
470
C0431 2113741F17 CAP CHIP CL2 X7R REEL
470
C0441 2113743L09 CAP CHIP 470 PF 10 X7R
C0442 2113743L09 CAP CHIP 470 PF 10 X7R
C0445 2113743L09 CAP CHIP 470 PF 10 X7R
C0446 2113743L09 CAP CHIP 470 PF 10 X7R
C0447 2113743L09 CAP CHIP 470 PF 10 X7R
C0448 2113743L09 CAP CHIP 470 PF 10 X7R
C0449 2113743L09 CAP CHIP 470 PF 10 X7R
C0470 2113743L09 CAP CHIP 470 PF 10 X7R
C0471 2113743N48 CAP CHIP 82.0 PF 5% COG
C0472 2113743N48 CAP CHIP 82.0 PF 5% COG
C0473 2113743N48 CAP CHIP 82.0 PF 5% COG
C0474 2113743L09 CAP CHIP 470 PF 10 X7R
C0476 2113743L09 CAP CHIP 470 PF 10 X7R
C0477 2113743L09 CAP CHIP 470 PF 10 X7R
Circuit
Ref
Motorola
Part No.
Description
C0478 2113743L09 CAP CHIP 470 PF 10 X7R
C0482 2113743L09 CAP CHIP 470 PF 10 X7R
C0483 2113743L09 CAP CHIP 470 PF 10 X7R
C0484 2113741F17 CAP CHIP CL2 X7R REEL
470
C0485 2113743L09 CAP CHIP 470 PF 10 X7R
C0486 2113743L09 CAP CHIP 470 PF 10 X7R
C0487 2113743L09 CAP CHIP 470 PF 10 X7R
C0488 2113743L09 CAP CHIP 470 PF 10 X7R
C0490 2113743L09 CAP CHIP 470 PF 10 X7R
C0491 2113743L09 CAP CHIP 470 PF 10 X7R
C0492 2113743L09 CAP CHIP 470 PF 10 X7R
C0493 2113743L09 CAP CHIP 470 PF 10 X7R
C0494 2113743L09 CAP CHIP 470 PF 10 X7R
C0495 2113743L09 CAP CHIP 470 PF 10 X7R
C0496 2113743L09 CAP CHIP 470 PF 10 X7R
C0497 2113743L09 CAP CHIP 470 PF 10 X7R
C0499 2113743L09 CAP CHIP 470 PF 10 X7R
C0501 2113741F49 CAP CHIP CL2 X7R REEL
10000
C0502 2113741F17 CAP CHIP CL2 X7R REEL
470
C0503 2113741F17 CAP CHIP CL2 X7R REEL
470
C0504 2113741F17 CAP CHIP CL2 X7R REEL
470
C0505 2113741F17 CAP CHIP CL2 X7R REEL
470
C0506 2113741F17 CAP CHIP CL2 X7R REEL
470
C0508 2113741F17 CAP CHIP CL2 X7R REEL
470
C0509 2113741F17 CAP CHIP CL2 X7R REEL
470
C0510 2113741F17 CAP CHIP CL2 X7R REEL
470
C0511 2113741F17 CAP CHIP CL2 X7R REEL
470
C0512 2113741F17 CAP CHIP CL2 X7R REEL
470
C0513 2113741F17 CAP CHIP CL2 X7R REEL
470
C0514 2113741F17 CAP CHIP CL2 X7R REEL
470
C0515 2113741F17 CAP CHIP CL2 X7R REEL
470
C0516 2113741F49 CAP CHIP CL2 X7R REEL
10000
C0517 2113743N48 CAP CHIP 82.0 PF 5% COG
C0518 2113741F17 CAP CHIP CL2 X7R REEL
470
Circuit
Ref
Motorola
Part No.
Description
C0541 2311049A05 CAP TANT CHIP A/P .47 10
25
C0542 2311049A99 CAP TANT CHIP 47 UF 10V
20
C0560 2113741F25 CAP CHIP CL2 X7R REEL
1000
C0591 2.11374E+26 CAP CHIP .10 UF 10%
C0592 2.11374E+26 CAP CHIP .10 UF 10%
C0593 2113741B69 CAP CHIP CL2 X7R REEL
100000
C0601 2113741F17 CAP CHIP CL2 X7R REEL
470
C0603 2389289U01 “10UF 50V 20, ALUMINUM
SMD”
C0611 2311049C06 CAP TANT CHIP 22 UF 35V
20%
C0612 2113743E26 CAP CHIP .10 UF 10%
C0622 2311049A99 CAP TANT CHIP 47 UF 10V
20
C0641 2113741F17 CAP CHIP CL2 X7R REEL
470
C0644 2311049A97 CAP TANT CHIP 33 UF 16V
20%
C0645 2113743E26 CAP CHIP .10 UF 10%
C0652 2311049A97 CAP TANT CHIP 33 UF 16V
20%
C0654 2311049A57 CAP TANT CHIP A/P 10UF
10% 16V
C0655 2113743E26 CAP CHIP .10 UF 10%
C0661 2311049C05 CAP TANT CHIP 47 UF 16V
10%
C0662 2113741F49 CAP CHIP CL2 X7R REEL
10000
C0663 2113743E26 CAP CHIP .10 UF 10%
C0671 2113743E26 CAP CHIP .10 UF 10%
C0681 2113743E26 CAP CHIP .10 UF 10%
C1002 2113741F49 CAP CHIP CL2 X7R REEL
10000
C1003 2113740F50 CAP CHIP REEL CL1 +/-30
91
C1004 2113740F57 CAP CHIP REEL CL1 +/-30
180
C1006 2113740F45 CAP CHIP REEL CL1 +/-30
56
C1007 2113740F57 CAP CHIP REEL CL1 +/-30
180
C1008 2113740F69 CAP CHIP CL1 +/-30 560 5%
C1009 2113740F57 CAP CHIP REEL CL1 +/-30
180
C1010 2113740F42 CAP CHIP REEL CL1 +/-30
43
Circuit
Ref
Motorola
Part No.
Description
