Motorola CDM1250 Service Manual

Low Band Range 2 (36–42 MHz) PCBs, Schematics, and Parts Lists Section 7: 4-61
6881091C63-F
Low Band Range 2 PCB 8486207B11 Parts
List
Circuit
Ref
Motorola
Part No.
Description
C0101 2113944C45 CAP, 100pF
C0107 2113945L25 CAP, 1000pF
C0112 2113945C31 CAP, .1uF
C0121 2113945C31 CAP, .1uF
C0122 2113945C31 CAP, .1uF
C0131 2113944C34 CAP, 22pF
C0132 2113944C34 CAP, 22pF
C0141 2113945C31 CAP, .1uF
C0151 2113945L49 CAP, .01uF
C0201 2313960D07 CAP, 10uF
C0202 2313960D07 CAP, 10uF
C0204 2113945C31 CAP, .1uF
C0212 2313960D07 CAP, 10uF
C0221 2113945C31 CAP, .1uF
C0222 2113945C31 CAP, .1uF
C0223 2113945C31 CAP, .1uF
C0224 2113944C45 CAP, 100pF
C0225 2113945C31 CAP, .1uF
C0226 2113945C31 CAP, .1uF
C0228 2313960B30 CAP, 4.7uF
C0231 2113955D31 CAP, 1uF
C0232 2113945C31 CAP, .1uF
C0234 2113945C31 CAP, .1uF
C0235 2113945C04 CAP, 22,000pF
C0236 2113945C25 CAP, .033uF
C0241 2113945C31 CAP, .1uF
C0243 2113944C45 CAP, 100pF
C0244 2113945C31 CAP, .1uF
C0245 2113945C31 CAP, .1uF
C0246 2113945L49 CAP, .01uF
C0251 2113945C31 CAP, .1uF
C0252 2313960B01 CAP, 1uF
C0254 2113945C31 CAP, .1uF
C0255 2113945C31 CAP, .1uF
C0256 2113944C45 CAP, 100pF
C0261 2113945C31 CAP, .1uF
C0262 2113944C43 CAP, 82pF
C0265 2113945C31 CAP, .1uF
C0267 2113945L49 CAP, .01uF
C0271 2113945C31 CAP, .1uF
C0272 2113945C31 CAP, .1uF
C0273 2113945L37 CAP, 3300pF
C0275 2313960F30 CAP, 47uF
C0276 2113945L25 CAP, 1000pF
C0277 2113945L25 CAP, 1000pF
C0290 2314030J26 CAP, 10uF
C0291 2314030J26 CAP, 10uF
C0292 2314030J26 CAP, 10uF
C0293 2314030J26 CAP, 10uF
C0421 2113944A38 CAP, 82pF
C0422 2113945L17 CAP, 470pF
C0423 2113945L17 CAP, 470pF
C0426 2113945A05 CAP, 470pF
C0427 2113945A05 CAP, 470pF
C0428 2113944A38 CAP, 82pF
C0429 2113945A05 CAP, 470pF
C0430 2113945L17 CAP, 470pF
C0431 2113945L17 CAP, 470pF
C0441 2113945A05 CAP, 470pF
C0442 2113945A05 CAP, 470pF
C0445 2113945A05 CAP, 470pF
C0446 2113945A05 CAP, 470pF
C0447 2113945A05 CAP, 470pF
C0448 2113945A05 CAP, 470pF
C0449 2113945A05 CAP, 470pF
C0470 2113945A05 CAP, 470pF
C0471 2113944A38 CAP, 82pF
C0472 2113944A38 CAP, 82pF
C0473 2113944A38 CAP, 82pF
C0474 2113945A05 CAP, 470pF
C0476 2113945A05 CAP, 470pF
C0477 2113945A05 CAP, 470pF
C0478 2113945A05 CAP, 470pF
C0482 2113945A05 CAP, 470pF
C0483 2113945A05 CAP, 470pF
C0484 2113945L17 CAP, 470pF
C0485 2113945A05 CAP, 470pF
C0486 2113945A05 CAP, 470pF
C0487 2113945A05 CAP, 470pF
C0488 2113945A05 CAP, 470pF
C0490 2113945A05 CAP, 470pF
C0491 2113945A05 CAP, 470pF
C0492 2113945A05 CAP, 470pF
C0493 2113945A05 CAP, 470pF
C0494 2113945A05 CAP, 470pF
C0495 2113945A05 CAP, 470pF
C0496 2113945A05 CAP, 470pF
C0497 2113945A05 CAP, 470pF
C0499 2113945A05 CAP, 470pF
C0501 2113945L49 CAP, .01uF
C0502 2113945L17 CAP, 470pF
C0503 2113945L17 CAP, 470pF
C0504 2113945L17 CAP, 470pF
C0505 2113945L17 CAP, 470pF
C0506 2113945L17 CAP, 470pF
C0508 2113945L17 CAP, 470pF
C0509 2113945L17 CAP, 470pF
C0510 2113945L17 CAP, 470pF
C0511 2113945L17 CAP, 470pF
Circuit
Ref
Motorola
Part No.
Description
C0512 2113945L17 CAP, 470pF
C0513 2113945L17 CAP, 470pF
C0514 2113945L17 CAP, 470pF
C0515 2113945L17 CAP, 470pF
C0516 2113945L49 CAP, .01uF
C0517 2113944A38 CAP, 82pF
C0518 2113945L17 CAP, 470pF
C0541 2313960A55 CAP, .47uF
C0542 2313960F30 CAP, 47uF
C0560 2113945A09 CAP, 1000pF
C0591 2113945C31 CAP, .1uF
C0592 2113945C31 CAP, .1uF
C0593 2113945H69 CAP, .1uF
C0601 2113945L17 CAP, 470pF
C0603 2389289U01 CAP, 10uF
C0611 2314030J28 CAP, 22uF
C0612 2113945C31 CAP, .1uF
C0622 2313960F30 CAP, 47uF
C0641 2113945L17 CAP, 470pF
C0644 2313960F04 CAP, 33uF
C0645 2113945C31 CAP, .1uF
C0652 2313960F04 CAP, 33uF
C0654 2313960D07 CAP, 10uF
C0655 2113945C31 CAP, .1uF
C0661 2314030H05 CAP, 47uF
C0662 2113945L49 CAP, .01uF
C0663 2113945C31 CAP, .1uF
C0671 2113945C31 CAP, .1uF
C0681 2113945C31 CAP, .1uF
C1001 2113944C88 CAP, 160pF
C1002 2113945L49 CAP, .01uF
C1003 2113944C91 CAP, 300pF
C1004 2113944C46 CAP, 120pF
C1006 2113944C40 CAP, 62pF
C1007 2113944C90 CAP, 240pF
C1008 2113945L25 CAP, 1000pF
C1009 2113944C90 CAP, 240pF
C1010 2113944C40 CAP, 62pF
C1011 2113944C46 CAP, 120pF
C1012 2113944C91 CAP, 300pF
C1013 2113945L49 CAP, .01uF
C1014 2113944C88 CAP, 160pF
C1015 2113945L49 CAP, .01uF
C1016 2113944C47 CAP, 150pF
C1017 2113945L27 CAP, 1200pF
C1019 2113944C90 CAP, 240pF
C1020 2113944C02 CAP, 220pF
C1021 2113944C91 CAP, 300pF
C1022 2113944C02 CAP, 220pF
C1023 2113944C91 CAP, 300pF
C1024 2113944C02 CAP, 220pF
Circuit
Ref
Motorola
Part No.
Description
C1025 2113944C90 CAP, 240pF
C1026 2113945L27 CAP, 1200pF
C1027 2113944C47 CAP, 150pF
C1028 2113945L49 CAP, .01uF
C1029 2113945L49 CAP, .01uF
C1030 2113945C31 CAP, .1uF
C1031 2113945C31 CAP, .1uF
C1032 2113944C42 CAP, 75pF
C1033 2113944C44 CAP, 91pF
C1034 2113944C45 CAP, 100pF
C1035 2113944C40 CAP, 62pF
C1036 2113945C31 CAP, .1uF
C1037 2113944C02 CAP, 220pF
C1038 2113944C91 CAP, 300pF
C1039 2113944C91 CAP, 300pF
C1040 2113944C02 CAP, 220pF
C1101 2113944C46 CAP, 120pF
C1102 2113944C44 CAP, 91pF
C1103 2113944C89 CAP, 200pF
C1104 2113945C31 CAP, .1uF
C1105 2113945C31 CAP, .1uF
C1106 2113945C31 CAP, .1uF
C1107 2113944C43 CAP, 82pF
C1108 2113945C31 CAP, .1uF
C1109 2113944C83 CAP, 36pF
C1110 NOT PLACED
C1111 2113944M03 CAP, 2.4pF
C1112 2113944C83 CAP, 36pF
C1113 2113945C31 CAP, .1uF
C1114 2113945C31 CAP, .1uF
C1115 2113944C46 CAP, 120pF
C1116 2113944C37 CAP, 39pF
C1119 2113945C31 CAP, .1uF
C1120 NOT PLACED
C1121 NOT PLACED
C1122 NOT PLACED
C1123 2113944C36 CAP, 33pF
C1124 2113945C31 CAP, .1uF
C1125 2113945C26 CAP, .039uF
C1126 2113945C31 CAP, .1uF
C1127 2313960D07 CAP, 10uF
C1128 2113945C31 CAP, .1uF
C1129 2113944C34 CAP, 22pF
C1130 2113944C41 CAP, 68pF
C1131 NOT PLACED
C1133 2113945C31 CAP, .1uF
C1134 2113945C31 CAP, .1uF
C1135 2113945C31 CAP, .1uF
C1136 2113945C31 CAP, .1uF
C1137 2113944C46 CAP, 120pF
C1138 2113945C31 CAP, .1uF
Circuit
Ref
Motorola
Part No.
Description
