Motorola CDM1250 Service Manual

Section 12: 4-10 UHF Band 1 (403–470 MHz) 25–40 W LDMOS PCB 8486127Z01, Schematics, and Parts Lists
6881091C63-F
UHF B1 25–40 W PCB 8486127Z01 Parts List
†
Circuit
Ref
Motorola
Part No.
Description
C0101 2113740F51 100pF
C0107 2113741F25 1000pF
C0112 2113743E20 0.1uF
C0121 2113743E20 0.1uF
C0122 2113743E20 0.1uF
C0131 2113740F35 22pF
C0132 2113740F35 22pF
C0141 2113743E20 0.1uF
C0151 2113741F49 10nF
C0201 2311049A57 10uF
C0202 2311049A57 10uF
C0204 2113743E20 0.1uF
C0212 2311049A57 10uF
C0221 2113743E20 0.1uF
C0222 2113743E20 0.1uF
C0223 2113743E20 0.1uF, 0662057B47, 0 Kohm
resistor for LS+ models
C0224 2113740F51 100pF
C0225 2113743E20 0.1uF
C0226 2113743E20 0.1uF
C0228 2311049A56 4.7uF
C0231 2113743B29 1uF
C0232 2113743E20 0.1uF
C0234 2113743E20 0.1uF
C0235 2113743E07 0.022uF
C0236 2113743E10 0.033uF
C0241 2113743E20 0.1uF
C0243 2113740F51 100pF
C0244 2113743E20 0.1uF
C0245 2113743E20 0.1uF
C0246 2113741F49 10nF
C0251 2113743E20 0.1uF
C0252 2311049A07 1uF
C0254 2113743E20 0.1uF
C0255 2113743E20 0.1uF
C0256 2113740F51 100pF
C0261 2113743E20 0.1uF
C0262 2113740F49 82pF
C0265 2113743E20 0.1uF
C0267 2113741F49 10nF
C0271 2113741F49 10nF
C0272 2113743E20 0.1uF
C0273 2113741F37 3300pF
C0275 2311049A99 47uF
C0276 2113741F25 1000pF
C0277 2113741F25 1000pF
C0301 2311049A07 1uF
C0302 2113743E20 0.1uF
C0303 2113740F51 100pF
C0304 2113743E20 0.1uF
C0305 2113743E20 0.1uF
C0324 2113743E20 0.1uF
C0331 2113743E20 0.1uF
C0341 2311049A07 1uF
C0342 2113743E20 0.1uF
C0343 2113743E20 0.1uF
C0344 2113743E20 0.1uF
C0351 2113743E20 0.1uF
C0352 2113743E07 0.022uF
C0353 2311049A97 33uF
C0354 2113743E20 0.1uF
C0421 2113743N48 82PF
C0422 2113741F17 470pF
C0423 2113741F17 470pF
C0426 2113743L09 470pF
C0427 2113743L09 470pF
C0428 2113743N48 82pF
C0429 2113743L09 470pF
C0430 2113741F17 470pF
C0431 2113741F17 470pF
C0441 2113743L09 470pF
C0442 2113743L09 470pF
C0445 2113743L09 470pF
C0446 2113743L09 470pF
C0447 2113743L09 470pF
C0448 2113743L09 470pF
C0449 2113743L09 470pF
C0470 2113743L09 470pF
C0471 2113743N48 82pF
C0472 2113743N48 82pF
C0473 2113743N48 82pF
C0474 2113743L09 470pF
C0476 2113743L09 470pF
C0477 2113743L09 470pF
C0478 2113743L09 470pF
C0482 2113743L09 470pF
C0483 2113743L09 470pF
C0484 2113741F17 470pF
C0485 2113743L09 470pF
C0486 2113743L09 470pF
C0487 2113743L09 470pF
C0488 2113743L09 470pF
C0490 2113743L09 470pF
C0491 2113743L09 470pF
C0492 2113743L09 470pF
C0493 2113743L09 470pF
C0494 2113743L09 470pF
C0495 2113743L09 470pF
C0496 2113743L09 470pF
C0497 2113743L09 470pF
Circuit
Ref
Motorola
Part No.
Description
C0499 2113743L09 470pF
C0501 2113741F49 10nF
C0502 2113741F17 470pF
C0503 2113741F17 470pF
C0504 2113741F17 470pF
C0505 2113741F17 470pF
C0506 2113741F17 470pF
C0508 2113741F17 470pF
C0509 2113741F17 470pF
C0510 2113741F17 470pF
C0511 2113741F17 470pF
C0512 2113741F17 470pF
C0513 2113741F17 470pF
C0514 2113741F17 470pF
C0515 2113741F17 470pF
C0516 2113741F49 10nF
C0517 2113743N48 82pF
C0518 2113741F17 470pF
C0541 2311049A05 0.47uF
C0542 2311049A99 47uF
C0560 2113743L17 1000pF
C0591 2113743E20 0.1uF
C0592 2113743E20 0.1uF
C0593 2113743E20 0.1uF, 0662057B47, 0 Kohm
resistor for LS+ models
C0601 2113741F17 470pF
C0603 2380090M24 10uF
C0611 2311049C06 22uF
C0612 2113743E20 0.1uF
C0622 2311049A99 47uF
C0641 2113741F17 470pF
C0644 2311049A97 33uF
C0645 2113743E20 0.1uF
C0652 2311049A97 33uF
C0654 2311049A57 10uF
C0655 2113743E20 0.1uF
C0661 2311049C05 47uF
C0662 2113741F49 10nF
C0663 2113743E20 0.1uF
C0671 2113743E20 0.1uF
C0681 2113743E20 0.1uF
C3101 2113740F34 20pF
C3102 2113740F31 15pF
C3103 2113740F39 33pF
C3104 2113743E20 0.1uF
C3110 2113740F37 27pF
C3111 2113743E20 0.1uF
C3112 2113740F49 82pF
C3114 2113740F33 18pF
C3115 2113740F35 22pF
C3116 2113743E20 0.1uF
Circuit
Ref
Motorola
Part No.
Description
C3121 2113743E20 0.1uF
C3122 2113743E11 0.039uF
C3123 2113743E11 0.039uF
C3124 2113740L30
NU
33pF 2% 3rd overtone crystal
fundamental crystal
C3132 2113743E20 0.1uF
C3133 2311049A57 10uF
C3134 2113743E20 0.1uF
C3135 2113740L30 33pF
C3136 2113740F35
2113740L29
22pF 3rd overtone crystal
30pF 2% fundamental crystal
C3137 2113743E11 0.039uF
C3139 2113743E20 0.1uF
C3140 2113743E20 0.1uF
C3141 2113743E20 0.1uF
C3142 2113743E20 0.1uF
C3143 2113740F53 120pF
C3144 2113743E20 0.1uF
C3145 2113743E20 0.1uF
C3146 2113741F41 4700pF
C3147 2113743E20 0.1uF
C3151 2113741F49 10nF
C3152 2113741F49 10nF
C4001 2113740F09 1.8pF
C4002 2113740F39 33pF
C4003 2113740F40 36pF
C4004 2113740F39 33pF
C4005 2113740F39 33pF
C4006 2113740F39 33pF
C4007 2113740F38 30pF
C4008 2113741F25 1000pF
C4009 2113740F27 10pF
C4010 2113741F13 330pF
C4011 2113741F37 3300pF
C4012 2113741F13 330pF
C4013 2113741F37 3300pF
C4014 2113740F51 100pF
C4015 2113740F51 100pF
C4017 2113740F09 1.8pF
C4018 2113740F29 12pF
C4019 2113740F29 12pF
C4020 2113740F39 33pF
C4021 2113740F39 33pF
C4022 2113740F39 33pF
C4023 2113740F29 12pF
C4024 2113741F25 1000pF
C4026 2113740F09 1.8pF
C4027 2113740F09 1.8pF
C4028 2113741F49 10nF
C4029 2113740F09 1.8pF
C4030 2113740F09 1.8pF
Circuit
Ref
Motorola
Part No.
Description
