Chapter 5 Laser Unit
5.5 Setting Up the LU-LR Four-laser PS Rack
1-198
5.5 Setting Up the LU-LR Four-laser PS Rack
CAUTION
1) The LU-LR four-laser PS rack is heavy. The laser rack weighs approximately 30 kg with
laser supplies unmounted. Do not attempt to lift or carry the four-laser PS rack by
yourself.
2) Unplug the two power cables of the LU-LR four-laser PS rack before mounting power
supplies into the four-laser PS rack.
3) Be sure to use the LU-LR four-laser PS rack power cables that meet the ratings.
4) If any trouble occurs in the LU-LR four-laser PS rack, unplug the two power cables of
the four-laser PS rack.
5.5.1 System Description
Overview
This unit is called the LU-LR four-laser PS rack. This rack houses power supplies for lasers in the laser unit,
and turns on multiple lasers or emits all lasers at a time. The rack can be mounted on top of the laser unit.
The following power sources manufactured by Melles Griot can be mounted in the rack:
Table 5.5-1 Mountable power sources
Violet Laser head: 56 ICS425
Power supply: 56 IMA 023
405 to 410 nm/38 mW
Laser head: 56 ICS426
Power supply: 56 IMA 023
440 to 445 nm/15 mW
Blue Laser head: IMA101040ALS
Power supply: 300 series
457 to 514 nm/40 mW
Laser head: IMA101065ALS
Power supply: 300 series
457 to 514 nm/65 mW
Laser head: 85BCD010, 020, 030 (CDRH supported)
Power supply: 85BCD series
488 ± 0.5 nm/10, 20, 30 mW
Green Laser head: 05LGP 193
Power supply: 05LPL951-065/100V, 05LPL915-065/115V/230V
543.5 nm/1 mW
Yellow Laser head: 85YCA010, 020, 025
Power supply: 85YCA series
561 nm/10, 20, 25 mW
Red Laser head: 56 ICS 264
Power supply: 56 IMA 022
638 nm/10 mW
To Next Page
