Chapter 8 Specifications and Performance
8.1 Overall Configuration
1-234
8.1.3 Photo Activation Illuminator Unit
Table 8.1-3
Unit Device Model name Remarks
Ti
Ti-E
Ti-E/B
Ti-U
Ti-U/B
Use the TI-DH Dia Pillar Illuminator
100W.
Objective
Use objectives appropriate for
specimens.
TI-LUSU The unit can be connected to a PC.
Shutter unit
TI-LU4SU
AC adapter
AD-1260B
EA1050E-120
For TI-LUSU shutter unit
Epi-fl filter turret
TI-FLC
TI-FLC-E
TI-FLC-E/HQ
Epi illumination lamp
and power supply
device
Make sure to read the instruction
manuals for the products.
26
Stage ring
(concentric ring)
32
Model 32 is made of glass.
Stage up kit TI-BSUK70
Microscope and
accessories
Back port unit TI-BPU
TI-BSUK70 70 mm stage up kit is
required.
Photo Activation
Illuminator Unit
TI-PAU
Illumination for PA-GFP or Epi
An optical path selector mirror is
required.
Photo Activation
Illuminator Unit
Optical fiber C1 single mode fiber
PC Commercially available
Monitor Commercially available
PA-GFP image
observation devices
TV camera (video
camera)
Commercially available
An adapter is required to connect to the
microscope port.
Two-laser unit C-LU2 See Section 8.1.4 for mountable lasers.
Three-laser unit C-LU3 See Section 8.1.4 for mountable lasers.
Three-laser unit EX C-LU3EX
See Section 8.1.4 for mountable lasers.
Included accessory
• Ar wavelength selector (C1-EX)
Laser unit
Four-laser module A LU4A
Filter slider cover
Filter cube port cover
retaining plate
Safety label
Ti laser safety kit
Protection plate for
nosepiece
