Chapter 1 System Configurations and Part Names
1.4 Name of Each Part
1-49
Optical path selector switch (on the microscope body)
Coarse
Fine
ExFine
Epi Shutter
FL Block
Refocus
Escape
L80
EYE
MEMORY
DISPLAY
ON
Z
-
RESET
1X
1.5X
BRIGHTNESS
R100
L100
FOCUS
PFS
Figure 1.4-21
The laser shutter does not open when the nosepiece
tube route of the optical path (“EYE”) is selected.
1.4.3 Motorized TIRF Illuminator Unit, LU4A, N-STORM and Ti-E System
When used with four-laser module A
POWER
TI-LU4SU
EMISSION
LASER
CAUTION
–
CLASS 3B
LASER RADIATION WHEN OPEN
AVOID EXPOSURE TO THE BEAM
CAUTION
–
CLASS 3B
LASER RADIATION WHEN OPEN
AVOID EXPOSURE TO THE BEAM
Figure 1.4-22
Optical path selector switch
Ti-E
EYE Observation port 100%
L100 Left port 100%
L80 Left port 80%
and observation port 20%
R100 Right port 100%
Ti-E/B
EYE Observation port 100%
L100 Left port 100%
L80 Left port 80%
and observation port 20%
B100 Bottom port 100%
Motorized TIRF illuminator
unit
Filter cube cover retaining
plate
Hub controller A
with AC ada
ter
HG fiber light source
Power supply device for
the diascopic illumination
Remote control pad
EM-CCD camera
TI-LU4SU shutter unit LU4
To laser unit
To laser unit
To PC
To laser unit
To PC
TI-FLC-E/HQ motor epi-fl
filter turret,
with protection plate
(part of laser safety kit)
3D-STORM port
STORM slide
