Nikon Eclipse TI-TIRF-E User Manual

Chapter 5 Laser Unit
5.5 Setting Up the LU-LR Four-laser PS Rack
1-201
5.5.2 Mounting Laser Power Supply
Mounting positions, clamps, and cables vary with the type of laser power supply. Select the clamp positions,
clamp types, and cables suitable for each laser supply.
Power supplies mounted
Table 5.5-2 Mounting Position
Wavelength Product Location Clamp Cable Procedure
Violet Laser head: 56RCS/S2780
Power supply: 56 IMA023
[2] [3] [2] 3.1
Laser head: 56RCS/S2781
Power supply: 56 IMA021
[2] [3] [2] 3.1
Blue Laser head: IMA101040ALS
Power supply: 300 series
[1] [1] [3], [5] 3.2
Laser head: IMA101065ALS
Power supply: 300 series
[1] [1] [3], [5] 3.2
Laser head: 85BCD010, 020, 030
(CDRH supported)
Power supply: 85BCD series
[4], [5] [3] [6], [7], [9] 3.3
Green Laser head: 05LGP 193
Power supply: 05LPL951-065/100V,
05LPL915-065/115V/230V
[3] [2] [4] 3.4
Yellow Laser head: 85YCA010, 020, 025
Power supply: 85YCA series
[4], [5] [3] [6], [7], [8] 3.3
Red Laser head: 56 ICS 264
Power supply: 56 IMA 022
[2] [3] [1] 3.1
