Nikon Eclipse TI-TIRF-E User Manual

1-231
Specifications and Performance
8
8.1 Overall Configuration
8.1.1 TIRF Illuminator Unit / Motorized TIRF Illuminator Unit― Configuration
for Normal Microscopy (Except N-STORM)
Table 8.1-1
Unit Device Model name Remarks
Ti-E
Ti-E/B
Ti-U
Ti
Ti-U/B
Use the TI-DH Dia Pillar Illuminator
100W.
Apo TIRF 60×H/1.49
Apo TIRF 100×H/1.49
Plan Apo TIRF 60×H/1.45
Plan Apo TIRF 100×H/1.45
Plan Apo VC 60×H/1.4
Objective for TIRF
microscopy
Plan Apo VC 100×H/1.4
Select the appropriate objective for
observations.
TI-LUSU The unit can be connected to a PC.
Shutter unit
TI-LU4SU For the four-laser module A.
AC adapter EA1050E-120 For TI-LUSU shutter unit
TI-FLC
TI-FLC-E
Epi-fl filter turret
TI-FLC-E/HQ
The TI-FLC-E/HQ comes with three
special high-precision filter cubes.
Fiber optic light source
Episcopic light
source
Lamphouse + power
supply
Make sure to read the instruction
manuals for the products.
26
Stage ring
(concentric ring)
32
Model 32 is made of glass.
Stage up kit TI-BSUK70
Microscope and
accessories
Back port unit TI-BPU
TI-BSUK70 70 mm stage up kit is
required.
TI-TIRF
TIRF
TI-TIRF-E
Two illumination modes are available,
TIRF (100%) and TIRF (60%)-Epi-fl
(40%).
Optical fiber C1 single mode fiber
A straight fiber can be used when used
with the straight fiber adapter.
Straight fiber adapter TIRF2 S
The adapter is attached to the
illuminator to use an optical fiber with a
straight tip.
TIRF/
motorized TIRF
illuminator unit
Stage up lens TI-TIRF Stage up lens
Use the stage up lens when a stage up
kit is installed and a TIRF/motorized
TIRF illuminator unit is attached to the
lower tier. The TI-BSUK70 70 mm
stage up kit is also required.
PC Commercially available
Monitor Commercially available
TIRF image
observation devices
TV camera (video
camera)
Commercially available
An adapter is required to connect to
the microscope port.

Nikon Eclipse TI-TIRF-E Specifications

General

Brand	Nikon
Model	Eclipse TI-TIRF-E
Category	Laboratory Equipment
Language	English
