Chapter 6 Connection between the Laser Unit and the Microscope
6.1 Setting and Connecting the TI-LUSU Shutter Unit
1-219
6.1.5 Communications Commands
(1) Standard commands
The following are factory default commands and can be used in the standard condition.
The shutter unit controls laser shutters so that only one shutter opens at a time in the standard condition.
1 c command: Operation, control, and data setting command
Table 6.1-3
c command
o: Normal
response
n: Error response
Description
cTSO(1)
oTSO
nTSO(6)
The command opens the specified shutter. The command closes the
specified shutter.
If an open time period has been specified, the shutter will close when
the specified period elapses.
Note that no shutter will open if the optical path for the binocular route
is open or the safety cover is open.
(1): [1-3] Shutter number
(6) :Error code
* The safety cover open/close condition is detected only for the
TIRF/motorized TIRF illuminator system.
cTSC
oTSC
nTSC(6)
The command closes all shutters.
cTTS(2):(3)
oTTS
nTTS(6)
The command sets up the shutter open time.
(2): [1-3] Shutter number
(3): [0000-1000] Time setting
* [0000] is used to open the shutter continuously. The value is
specified in steps of 0.1 seconds. (100.0 seconds maximum)
Example: 0001 for 0.1 seconds
(6): Error code
cTSW(4)
oTSW
nTSW(6)
The command enables/disables the laser open/close switch on the
control panel.
(4): [1] Enabled, [0] Disabled
(6): Error code
