Chapter 5 Laser Unit
5.1 Overview of the Laser Units
2-46
(6) Interlock cable connectors
CONF: Do not use in this system.
MIC: This connector is for the interlock cable to connect a microscope.
TIRF: This connector is for a cable to connect the laser safety cover.
(7) LUSU connector
This connector is for cables to connect the shutter unit LU4.
(8) USB connector
This connector is for a USB cable to connect a PC.
(9) LD connector
This connector is for future expansion. (Do not use in this system. Otherwise, a malfunction occurs.)
Precautions when handling the laser unit
• The laser head and the optical fiber are precisely aligned in these units.
Avoid subjecting the laser head or optical fiber to vibration or shock. Contact the distributor
if you need to remove the laser head from the unit due to laser malfunction or other reasons.
To Next Page
