Engine System - LPG LEV
197
Service Manual – CS7000
Special T
ools
KGST Software.
Download from EZparts
Password for use with the WGG972GL-E4 (LEV) engine:
LayVijZuWSOp
Diagnostic Cable Adapter Part# 56511575
Used to connect ECOM cable to Kubota LEV diagnostic
connector
ECOM Cable - Diagnostic Communication Cable and software, p/n
56305647
Note: The “Ecom” cable is used but the software on the
CD is for the GM engines.
LPG test gauge kit - Part # 56504450
