Control System 78Service Manual – CS7000
Specications
Shop Measurements – Main Machine Controller
The following tables contain some “real world” shop voltage measurements to help you recognize what
“normal” looks like. All voltage values were measured with the black (Negative) voltmeter lead connected to
the main battery negative unless otherwise specied.
J2 Connector (White)
J2 Pin Wire Circuit Description Value/Condition
1 091 ORN/YEL Left Front Turn Lamp 10.3v when off 0.02v when on
2 094 ORN/BLU Left Rear Stop/Turn Lamp 11.1v when off 0.01v when on
3 098 YEL/RED Right Front Turn Lamp 10.3v when off 0.02v when on
4 101 YEL/GRN Right Rear Stop/Turn Lamp 11.1v when off 0.01v when on
5 107 TAN/BLK Tail Lamps 5.1v when off 0.01v when on
6 064 BLK/YEL Dust Control Motor Contactor
Grounds to energize
0.07v when energized 37v when not
energized
7 119 BRN/WHT Detergent Pump (M17) Pulsed voltage is too fast for useful
measurement value
8 080 WHT/GRN Squeegee Actuator Motor 37v at rest or when going down 0.04
going up
9 078 BLU/BRN Squeegee Actuator Motor 37v at rest or when going up 0.01v going
down
10 132 RED/GRN Scrub Deck Actuator Motor 37v at rest or when going down 0.15v
going up
11 135 YEL/GRA Scrub Deck Actuator Motor 37v at rest or when going up 19v going
down
12 162 BLK Battery Negative 0.001v scrub and sweep systems running
13 057 VIO VACC 1 Power supply from
Aux Contactor
0v Key Off 37v Key On (Aux Contactor
energized)
14 051 BLK/ORN Auxiliary Contactor Grounds to
energize
0.07v when energized 37v when not
energized
15 163 BRN/BLK Side Broom Motor Contactor
Grounds to energize
0.08v when energized
16 063 GRN/GRA Main Broom Motor Contactor
Grounds to energize
0.08v when energized
17 045 BLU Vacuum Motor Contactor
Grounds to energize
0.08v when energized
18 150 BLK/RED Shaker Motor PWM ground 10.6v shaker motor running
