10. Remove the board.
Re-installation
1. When you re-install the board, be sure to re-connect the ground wires at the upper left corner and
center of the main board.
2. If the main board has been replaced, be sure to do the procedures for after replacing a main
board. ( p.130 "After Replacing the Main Board")
After Replacing the Main Board
Do the procedures below after replacing the main board of the M101, M103, or M103.
1. Start Smart Organizing Monitor.
4. Replacement and Adjustments
130
