Safety, Symbols, Trademarks
Conventions
Commonly Used Icons for Replacements and Adjustments
Symbol What it means
Binding screw (shoulder hexagonal head)
Binding screw (round flathead)
Black screw (heavy, fusing unit, TCRU)
Bushing
C-ring
Connector
E-ring
FFC (Flat Film Connector)
FFC (Flat Film Connector)
Gear
Harness clamp
Harness clamp (metal: fusing unit)
Hook (or tab release)
Knob screw (black)
Knob screw (sliver)
Pivot screw
Screw (common screw)
Shoulder screw
Spring
