17. The pickup roller and shaft are replaced as one unit (the roller is permanently attached to the shaft).
Friction Pad
1. Press the pinch releases on each side ( x2).
2. Rotate and raise the pad.
3. Pull the pad straight up of the shaft to remove it.
4. Replacement and Adjustments
92
