Flatbed Scanner (M103)
Preparation
• Front cover ( p.60 "M103 Covers, Flatbed Unit, ADF")
• Right cover
• Left cover
• Flatbed Unit, ADF
1. Lay the flatbed unit on a flat surface with the exposure glass down.
2. Disconnect the bottom of the unit, and then turn over so the exposure glass is facing up ( x6).
3. Separate the top and bottom of the flatbed unit.
CIS
Preparation
• Separate flatbed unit ( p.144)
4. Replacement and Adjustments
