• There are three tabs on the bottom.
• There is one tab on the back.
2. Lift the machine slightly.
3. Release the tab on the back ( x1).
4. Release the tabs on the bottom ( x3).
5. Separate the cover from the right side of the machine.
Left Cover
Preparation
Remove:
• Front cover
•
Top cover
1. Separate the tabs at the rear and front ( x2).
4. Replacement and Adjustments
48
