A: SEF
B: LEF
Throughout this service manual, "SEF" denotes "Short Edge Feed" and "LEF" denotes "Long Edge Feed".
Machine Names
Printer Name Model No.
SG20101L J027
SG2100 J028
SG3100 J029
SG K3100 J035
• Throughout this manual the machines are referenced by the model numbers only: J027, J028,
J029 or J035.
•
The J027 has the ZICO controller. This model has a NIC mounted on the controller board. The
J027 controller does not support PCL.
• The J028, J029 and J035 have the FIGO controller. All models have a NIC mounted on the
controller board. This controller is PCL compatible.
Warnings, Cautions, Notes
In this manual, the following important symbols and notations are used.
• A Warning indicates a potentially hazardous situation. Failure to obey a Warning could result in
death or serious injury.
• A Caution indicates a potentially hazardous situation. Failure to obey a Caution could result in
minor or moderate injury or damage to the machine or other property.
8
