Key Summary Table
Key/Indicator What It Does
1 Power Press this key to turn the power on. To turn the power off, press and hold
down this key for one second.
Blinks when the printer is receiving data from a computer or if there is data
to be printed.
2 Job Reset When the machine is online, press this key to cancel an ongoing print job.
3 Form Feed When the printer is offline, push to print all the data in the printer buffer.
If there is a paper jam, press this key according to the displayed error
message and remove the jammed paper.
4 Escape Push to restore the display to the previous condition.
5 [
]
[ /Menu]
[ ], [ /Menu]: Increase or decrease values on the display when making
settings.
[ /Menu]: When the printer is in standby mode, press [ /Menu] key to
enter the user menu.
6 Cartridge
replacement
indicator
Show the ink levels of the print cartridges.
7 Waste ink full
indicator
Show the waste ink levels of the ink collector unit.
8 Display Shows the current printer status and error messages.
9 Alert indicator The symbol appears in the LCD when an error occurs.
•
Red indicator illuminating: Indicates an error that requires the
operator or service representative to deal with. Printing stops.
• Red indicator flashing: An alert message appears. Follow the
instruction that appears in the display.
10 #Enter Push to execute the menu item on the display.
11 No-Fuss Head
Cleaning
When the machine is in standby mode, press the [Job Reset] and [Form
Feed] keys at the same time to perform head cleaning for all colors. EU
models also equip this function although these have no text on the
operation panel.
Using the Operation Panel
29
