On the other hand, "Ink C.U. Space" in the machine's menu on the control panel displays the available
storage space left in the ink collector unit. (It is reset to 100% if a new ink collector unit is installed.)
Display Menu Summary
Here is a summary of the function menus. Items needed for printer maintenance or troubleshooting are
marked in the left column with an asterisk (*).
User Menu Mode
Menu/Menu Item Function
Counter
*2
Displays or prints the number of pages printed in B&W, full color, and
Economy Color.
Note: Changing Bit SW 5 modifies the display:
•
Setting Bit SW 5-6 to "0" switches the Economy Color display off.
• The default setting for Bit SW 5-6 is "1". Mono and Economy Color are
both displayed.
Show Counter Displays the counters on the LCD ("Black", "Color")
Print Prints the "Page Counter" report that lists: the machine serial number, Total
Full Color, Total Mono Color, Total Economy Color, and Total Duplex. It
also lists Coverage information for full color, mono, and Economy Color.
Paper Input
Paper Type Specifies type of paper loaded in the paper tray.
Tray Paper Size Specifies size of paper to be loaded in the paper tray.
Note: The setting of Bit SW6-7 determines whether hidden functions (hidden
paper sizes A5 SEF, B6 SEF) are displayed:
•
0: No A5 SEF, B6 SEF display (default)
• 1: A5 SEF, B6 SEF displayed
Aut. Tray Select Specify that the paper tray be automatically selected. The paper tray will
automatically be selected according to the paper size and paper type. Tray
1 (the standard paper cassette) is the default. "Tray 2" and "Tray 3" appear
only if the paper feed unit(s) is attached. "Bypass Tray" appears only if the
bypass tray is attached.
2. Installation
32
