1-002-014 REG:TR3:GROS:F (FA)
Adjust Main Scan Registration (Glossy Paper:
Tray 3)
1-002-015 REG:TR3:GROS:U
Use this SP code to adjust writing in the main scan direction for glossy paper
loaded in Tray 3. Do this setting when registration does not match the image start
position on the user image adjustment menu.
[-128 to +127/FA/1/0.1mm]
1-002-016 REG: MAN:GROS:F (FA)
Adjust Main Scan Registration (Glossy Paper:
Bypass Tray)
1-002-017 REG: MAN:GROS:U
Use this SP code to adjust writing in the main scan direction for glossy paper
loaded in Bypass Tray. Do this setting when registration does not match the image
start position on the user image adjustment menu.
[-128 to +127/FA/1/0.1mm]
Charge Width Setting Mj1,2 : Simplex (DFU)
1-010-001 CHG:W1:EDGE:1 LE/TE: Mj1,2: ID1
1-010-002 CHG:W1:MIDL:1 MIDLL: Mj1,2: ID1
1-010-003 CHG:W1:EDGE:2 LE/TE: Mj1,2: ID2
1-010-004 CHG:W1:MIDL:2 MIDLL: Mj1,2: ID2
1-010-005 CHG:W1:EDGE:3 LE/TE: Mj1,2: ID3
1-010-006 CHG:W1:MIDL:3 MIDL: Mj1,2: ID3
1-010-007 CHG:W1:EDGE:4 LE/TE: Mj1,2: ID4
1-010-008 CHG:W1:MIDL:4 MIDL: Mj1,2: ID4
Charge Width Setting Mj3,4,5 : Simplex (DFU)
1-010-009 CHG:W1:EDGE:9 LE/TE: Mj3,4,5: ID1
1-010-010 CHG:W1:MIDL:9 MIDLL: Mj3,4,5: ID1
1-010-011 CHG:W1:EDGE:10 LE/TE: Mj3,4,5: ID2
SP Mode Service Tables
43
