Ricoh IM C4510 User Manual

Machine and Options Specifications
379
9
Item
Specifications
Power
requirements
Power is supplied from the main unit.
Maximum
power
consumption
13 W or less
Dimensions
(W × D × H)
340 × 544.5 × 290 mm (13.4 × 21.5 × 11.5 inches) (except
protruding parts)
Weight
Approx. 11 kg (24.3 lb.)
Specifications for Caster Table
Item
Specifications
Dimensions
(W × D × H)
587 × 616 × 76 mm (23.1 × 24.3 × 3.0 inches) (except protruding
parts)
Weight
Approx. 9 kg (19.9 lb.)
Specifications for Wireless LAN Board
• Note that the available channels (frequency ranges) and locations to use the
wireless LAN are subject to the regulations of the country or region where the
printer is used. Be sure to use the wireless LAN according to the applicable
regulations.
Item
Specifications
Transmission
spec
Based on IEEE 802.11a/b/g/n/ac (wireless LAN)
Transmission
rate
• 2.4 GHz band: 72.2 Mbps (maximum)
• 5 GHz band: 433.3 Mbps (maximum)
Frequency
range (Center
Frequency)
IEEE 802.11a
• 5180–5240 MHz (36, 40, 44, and 48 channels)
• 5260–5320 MHz (52, 56, 60, and 64 channels)
• 5500–5700 MHz (100, 104, 108, 112, 116, 120, 124, 128, 132,
136, and 140 channels)
• 5745–5825 MHz (149, 153, 157, 161, and 165 channels)

Ricoh IM C4510 Specifications

General

Category	All in One Printer
Print Speed	45 ppm
Print Resolution	1200 x 1200 dpi
Copy Speed	45 cpm
Copy Resolution	600 x 600 dpi
Standard Functions	Print, Copy, Scan, Fax
Warm-up Time	21 seconds
Hard Disk Drive	320 GB
Monthly Duty Cycle	150, 000 pages
Type	Laser
Scan Resolution	600 dpi
Fax Resolution	200 x 200 dpi
Paper Capacity	Standard: 1, 200 sheets; Maximum: 4, 700 sheets
Duplex Printing	Yes
Network Connectivity	Ethernet, Wi-Fi, USB
Memory	2 GB RAM
Control Panel	10.1" Smart Operation Panel
Operating System Compatibility	Windows, Mac, Linux
