Ricoh IM C4510 User Manual

Placing an Original and Loading Paper
81
1
• If you will not fix the end fence, put the stopper in the position as shown in the
illustration, and then rotate the fixing screw 90 degrees clockwise with a coin or
similar object.
8. Push the tray in the original position carefully.
To return the completely pulled out tray to the original position, push the tray
straight in. If the paper tray is damaged, it may cause a paper jam. Also, if you push
the tray forcibly, the side fence of the tray may be moved.
• You can load envelopes into Tray 2 to 4.
page296”Envelope Orientation and Recommended Status”
Loading Paper into the Bypass Tray
Use the bypass tray to load paper of a size that cannot be loaded into Tray 1 to 4, such as
label paper (adhesive labels).
The maximum number of sheets you can load at the same time depends on paper type.
page285”Recommended Paper Sizes and Types”
• Do not stack paper over the limit mark. If you load paper over the limit mark, the
print image may be slanted or the paper may be jammed.

Ricoh IM C4510 Specifications

General

Category	All in One Printer
Print Speed	45 ppm
Print Resolution	1200 x 1200 dpi
Copy Speed	45 cpm
Copy Resolution	600 x 600 dpi
Standard Functions	Print, Copy, Scan, Fax
Warm-up Time	21 seconds
Hard Disk Drive	320 GB
Monthly Duty Cycle	150, 000 pages
Type	Laser
Scan Resolution	600 dpi
Fax Resolution	200 x 200 dpi
Paper Capacity	Standard: 1, 200 sheets; Maximum: 4, 700 sheets
Duplex Printing	Yes
Network Connectivity	Ethernet, Wi-Fi, USB
Memory	2 GB RAM
Control Panel	10.1" Smart Operation Panel
Operating System Compatibility	Windows, Mac, Linux
