Setting Item Description
01: Black 1
02: Black 2
03: Cyan 1
04: Cyan 2
05: Magenta 1
06: Magenta 2
07: Yellow 1
08: Yellow 2
Press [Execute] to execute the function.
Open the toner bottle cover in advance.
Press the knob below the bottle to remove it after
execution.
0506: Execute Developer Refreshing
Replace some part of developer inside the Development Unit
It may alleviate the symptom when the followings occurs on the printed pages:
• Background appear stained
• White spots appear
• Print density is uneven
• Black items appear faint
Setting Item Description
01: All Colors
02: Black
Press [Execute] to execute the function.
0507: Execute Photoconductor Refreshing
Clean the drum surface. It take about 4 minutes to execute. Do not open the front cover during
execution.
Setting Item Description
01: Execute Press [Execute] to execute the function.
5. Adjustment Settings for Operators
190
