10. Close the Banner Sheet Tray Top Board.
11. Close the cover of Extension LCT banner sheet tray.
• Remove and store the auxiliary fences or fence from the machine when you are not using them.
Loading Paper into the Multi Bypass Tray (Tray A)
Use the multi bypass tray (Tray A) to use transparencies, translucent paper, and paper that cannot be
loaded in the paper trays.
• The maximum number of sheets you can load at the same time depends on paper type. Do not
stack paper over the limit mark. For the maximum number of sheets you can load, see below.
• page 98 "Recommended Paper Sizes and Types"
• Check the paper edges are aligned at the left side.
• When loading a low number of sheets, be sure not to squeeze the fences in too tightly. If the fences
are squeezed too tightly against the paper, the edges may crease, the paper may misfeed, or if it
weighs between 52.3–63.0 g/m
2
(14.0–16.9 lb. Bond), it may wrinkle.
1. Set the fences to the paper, and then square the paper and load it print side up.
Do not stack paper over the limit mark.
2. Paper Specifications and Adding Paper
88
