Ricoh Pro C9500 User Manual

Booklet Finisher
• Open the finisher
front cover.
• Pull handle Rb18,
and then pull out
staple unit
• Turn knob Rb19
counter clockwise to
rotate the staple unit.
• Pull out the Waste
Staple Receptacle,
then empty it.
• Put the receptacle
back.
• Pull out the cartridge. • Push the knob at the
end of the face plate
upward to open it.
• Remove jammed
staple, and then push
the knob at the end of
the face plate
downward to close
the face plate.
• Hold the lever and
push in the cartridge
until it clicks, then
raise the lever.
• Push the cartridge until it clicks.
• Return the staple unit to its original
position.
• Close the finisher front cover.
M0EDIM2397
When a Staple Is Jammed
251
