Load the Test Data

1. The File Type item displays the file type that can be loaded. It is specified as *.csv.

2. Click or tap the File Path input field and the "Disk" menu is displayed. Select the

desired target file and then click or tap

OK to select the file. For details about the

Disk menu, refer to

Disk Management

3. Click or tap Load to load the file. The saved test data will be displayed on the

screen in a wave/chart format (depending on the display type setting).

Bode Plot (for DHO914S and DHO924S only)

DHO900 User Guide

184
