25.1 Remote Control via USB
1. Connect the device
Use the USB cable to connect the rear-panel USB DEVICE interface of the
instrument to the USB HOST interface of the PC.
2. Search for the device resource
Start up Ultra Sigma and the software will automatically search for the resource
currently connected to the PC via the USB interface. You can also click
USB-TMC to
search for the resource.
3. View the device resource
The resources found will appear under the "RIGOL Online Resource" directory, and
the model number and USB interface information of the instrument will also be
displayed.
4. Control the instrument remotely
Right-click the device resource name and select "SCPI Panel Control" to open the
remotely command control panel. Then you can send commands and read data
through the panel. For details about the SCPI commands and programming, refer
to the Programming Guide of this instrument.
25.2 Remote Control via LAN
1. Connect the device
Use the network cable to connect the instrument to your local area network (LAN).
2. Configure network parameters
Configure the network parameters of the instrument according to
I/O Setting
.
3. Search for Search device resource
Start up Ultra Sigma and click LAN to open the panel as shown in the figure below.
Click
Search and the software searches for the instrument resources currently
connected to the LAN and the resources found are displayed at the right section of
the window as shown in the figure below. Click OK to add it.
Remote Control
DHO900 User Guide
258
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
