Rigol DS1000Z Series User Manual

Chapter 6 To Make Measurements RIGOL
DS1000Z User’s Guide
6-15
Base 10 Logarithm
Calculate the base 10 logarithm of specified signal source point by point and display
the results.
Press MATH  Math  Operator to select “lg”:
 Press Display to turn on or off the base 10 logarithm operation function.
 Press Source to select the desired channels (CH1, CH2, CH3 or CH4).
 Press Offset and use to adjust the vertical offset of the operation result.
 Press Scale and use to adjust the vertical scale of the operation results.
 Press Scale Reset, the instrument will adjust the vertical scale to the best value
according to the current configration automatically.
 Press Options to set the start point, end point or turn on or off the inverted
display of the operation results.
Press Start to set the start point of the operation results.
Press End to set the end point of the operation results.
Press Invert to turn the inverted display of the operation results on or off.
Press Auto Scale to turn on or off the auto scale function. When “ON” is
selected, the instrument will adjust the vertical scale to the best value according
to the current configration automatically.
 HORIZONTAL POSITION and HORIZONTAL SCALE can also be
used to adjust the horizontal position and scale of the operation results.
Natural Logarithm
Calculate the natural logarithm of specified signal source point by point and display
the results.
Press MATH  Math  Operator to select “ln”:
 Press Display to turn on or off the natural logarithm operation function.
 Press Source to select the desired channels (CH1, CH2, CH3 or CH4).
 Press Offset and use to adjust the vertical offset of the operation result.
 Press Scale and use to adjust the vertical scale of the operation results.
 Press Scale Reset, the instrument will adjust the vertical scale to the best value
according to the current configration automatically.
 Press Options to set the start point, end point or turn on or off the inverted
