Chapter 12 Signal Source RIGOL

DS1000Z User’s Guide

12-7

To Output Built-In Waveform

7 kinds of built-in waveforms are provided by signal source builted-in the DS2000A

series odcilloscope, including Sinc, Exp.Rise, Exp.Fall, ECG, Guass, Lorentz,

Haversine.

Sinc

The figure below shows a Sinc waveform.

Exponential Rise

The figure below shows an Exponential Rise waveform.

Exponential Rise

The figure below shows an Exponential Rise waveform.
