Rigol DS1000Z Series User Manual

RIGOL Chapter 11 Display Control
DS1000Z User’s Guide
11-2
To Select the Display Type
Press Display  Type to set the waveform display mode to “Vectors” or “Dots”.
 Vectors: the sample points are connected by lines and displayed. Normally, this
mode can provide the most vivid waveform to view the steep edge of the
waveform (such as square waveform).
 Dots: display the sample points directly. You can directly view each sample point
and use the cursor to measure the X and Y values of the sample point.
