Chapter 11 Display Control RIGOL
DS1000Z User’s Guide
11-5
To Set the Waveform Intensity
Press Display  WaveIntensity or turn when the menu is hidden to adjust
the waveform brightness of the analog channel. The default is 50% and the range
available is from 0% to 100%.
To Set the Screen Grid
Press Display  Grid to set the screen grid type.
 : turn the background grid and coordinate on.

: turn the background grid off.

: turn the background grid and coordinate off.
To Set the Grid Brightness
Press Display  Brightness to set the brightness of the screen grid. Turn to
adjust the grid brightness. The default is 50% and the range available is from 0% to
100%.
To Set the Menu Display
Press Display  Menu Display to set the menu display time. The menu will hold
for a specified period of time after the last button-pressing action and then is hidden.
The display time can be set to 1 s, 2 s, 5 s, 10 s, 20 s or Infinite (the menu will not be
hidden).
