RIGOL Chapter 13 Store and Recall

DS1000Z User’s Guide

13-2

Storage System

Press Storage to enter the store and recall setting interface.

This oscilloscope provides a USB Host interface at the front panel to connect USB

storage device for external storage and the internal memory capacity (Local Disk) is

90.5 MByte. The USB storage device connected is marked as “Disk D”.
