Chapter 9 Pass/Fail Test RIGOL
DS1000Z User’s Guide
Chapter 9 Pass/Fail Test
Monitor the change of the signal by judging whether the input signal is within the
mask created. The test results can be displayed on the screen as well as be declared
through the system sound or the pulse signal output from the [Trigger Out]
connector at the rear panel.
The contents of this chapter:
To Enable Pass/Fail Test
To Select Source
Mask Range
Test and Ouput
To Save the Test Mask
To Load the Test Mask
