Rigol DS1000Z Series User Manual

RIGOL Chapter 1 Quick Start
DS1000Z User’s Guide
1-18
bottom of the screen.
Acquire: press this key to enter the sample setting menu to set the acquisition
mode, Sin(x)/x and memory depth of the oscilloscope.
Storage: press this key to enter file store and recall interface. The storable file
types include picture, traces, waveforms, setups, CSV and parameter. Internal and
external storage as well as disk management are also supported.
Cursor: press this key to enter cursor measurement menu. The oscilloscope
provides three cursor modes: manual, track and auto.
Display: press this key to enter display setting menu to set the display type,
persistence time, wave intensity, grid type, grid brightness and menu display time of
the waveform.
Utility: press this key to enter the system function setting menu to set the
system-related functions or parameters, such as I/O setting, sound and language.
Besides, some advanced functions (such as pass/fail test, waveform record) are also
supported.
Print
pressing this key will save the screen to the USB storage device in
“.png” format. If the current storage type is picture, the screen will be
saved in the USB storage device in picture format (BMP8, BMP24, PNG
and TIFF).
