Chapter 12 Signal Source RIGOL
DS1000Z User’s Guide
12-17
To Edit Waveforms
Users can edit the waveforms which have been already saved. Press Edit to enter
the waveform editing interface.
1. Interpolation
Press Interp to turn the interpolation between the defined waveform points on or
off.
 ON: the waveform editor will connect the two points with a straight line.
 OFF: the waveform editor will hold a constant voltage level between two
points and create a step waveform.
2. Zoom
Press Zoom to turn the zoom function on or off.
 ON: only displays the current point in the middle of the waveform editor
window.
 OFF: displays all the initial points in the waveform editor window.
3. Current point
Press CurPoint and use to set the desired points currently edited and the
range available is from 1 to the initial points.
Method one:
Rotate
directly to set the desired points currently edited.
Method two:
Press
to input desired paramrter values and unist directly using the pop-up
numeric keyboard.
4. Voltage
Press Voltage to set the voltage value of the current point and the range
available is from -2.5 V to +2.5 V.
Method one:
Rotate
directly to set the desired voltage value.
Method two:
Press
to input desired paramrter values and unist directly using the pop-up
numeric keyboard.
