Rigol DS1000Z Series User Manual

RIGOL Chapter 15 Remote Control
DS1000Z User’s Guide
15-6
Remote Control via LAN
1. Connect the device
Connect the oscilloscope to your LAN using a network cable.
2. Configure network parameters
Configure the network parameters of the oscilloscope according to the
description in “
LAN Setting”.
3. Search device resource
Start up the Ultra Sigma and click
. The window as shown in the
figure below is displayed. Click
(as shown in Figure (a)) and the
software searches for the oscilloscope resources currently connected to the LAN
and the resources found are displayed at the right of the window. As shown in
Figure (b), select the desired resource name and click
to add it.
Note that if you want to remove the unwanted resource, select the resource
name and click
(as shown in Figure (c)).
Figure (a)
