Measurement Setting
1. Source Selection
Press Measure  Source to select the desired channel for measurement
(CH1-CH4). The color of the parameter icons under MENU at the left of the
screen will change with the source selected.
2. Delayed Measurement Setting
Specify the source A and source B in the measurement items “Delay A→B ”
and “Delay A
→B ”.
Press Measure  Setting  Type  “Delay” and then press SourceA and
SourceB to set the two channel sources (CH1-CH4) of delayed measurement
respectively.
3. Phase Measurement Setting
Specify the source A and source B in the measurement items “Phase A→B ”
and “Phase A
→B ”.
Press Measure  Setting  Type  “Phase” and then press SourceA and
SourceB to set the two channel sources (CH1-CH4) of phase measurement
respectively.
4. Threshold Measurement Setting
Specify the vertical level (in percentage) being measured in the analog channel.
Measurements of all the time, delay and phase parameters will be influenced by
this setting.
Press Measure  Setting  Type  “Threshold” and then:
 Press Max and use to set the maximum value of the measurement.
Reducing the maximum value to the current “Mid” will automatically reduce
the “Mid” to keep it lower than the maximum value. The default is 90% and
the range available is from 7% to 95%.
 Press Mid and use to set the middle value of measurement. The middle
value is limited by the settings of “Max” and “Min”. The default is 50% and
the range available is from 6% to 94%.
 Press Min and use to set the minimum value of the measurement.
Increasing the minimum value to the current “Mid” will automatically
increase the “Mid” to keep it higher than the minimum value. The default is
10% and the range available is from 5% to 93%.
