Chapter 12 Signal Source
It is particularly suitable for the test application of excitation-response with the
dual-channel, 25 MHz signal source built-in the oscilloscope and it is very convenient
for the engineers who need both signal source and oscilloscope to combine the signal
source with the oscilloscope. This chapter will introduce how to use the signal source
builted-in the oscilloscope. As the function and the setting method of the two
channels of the signal are the same, this chanpter only takes source1 setting for
illustration.
Press Source menu key to enter the signal setting interface:
Press Output to turn the signal output on or off. After “ON” is selected, the
instrument will output the signal currently set from the [Source1] connector at the
rear panel.
Note: you also can turn on the signal output by the Output under the Src1 Setup
submenu.
Press Src1 Setup to select the signal type currently output and set the relative
parameters of the signal.
Press StatusDisp to view the current signal status of SOURCE1 and SOURCE2, for
example, frequency, amplitude, offset, phase, modulation type and modulation
frequency.
The contents of this chapter:
 To Output Basic Waveform
 To Output Built-In Waveform
 To Output Arbitrary Waveform
