Rigol DS1000Z Series User Manual

Chapter 13 Store and Recall RIGOL
DS1000Z User’s Guide
13-5
Internal Storage and Recall
Internal storage and recall support “Setups” in Storage. In the following part, the
storage and recall method and procedures are introduced.
1. Save the specified oscilloscope setting in internal memory.
1) Connect the signal to the oscilloscope and obtain stable display.
2) Press Storage  Storage to select “Setups”, press Save and use to
select “Local Disk” (appears as blue shading) and press down to open
the local disk.
3) Press New File to creat a file name using the pop-up keyboard and for
specific operations please refer to the instruction of “
To Create a New File
or Folder”. If the internal memory has saved files in this type, use to
select the file and Save and Delete areilluminated, at this point, press
Save to execute the saving operation, the original file can be overwritten or
be delected by pressing Delete. Use to select and then press
down
to return to the previous directory.
2. Load the specified type of file in internal memory.
1) Press Storage  Storage to select “Setups” and then press Load and use
to select “Local Disk” and then press down to open the local disk.
2) If the internal memory has saved files in this type, use
to select the
desired file to load and press Load to load the file selected.
