RIGOL Chapter 13 Store and Recall
DS1000Z User’s Guide
13-6
External Storage and Recall
Before using external storage and recall, make sure that the USB storage device is
connected correctly. External storage supports all the types of files in Storage but in
recall, “Picture”, “CSV” and “Param”are not supported.
1. Save the specified type of file in the external USB storage device.
1) Connect the signal to the oscilloscope and obtain stable display.
2) Press Storage  Storage to select “Traces”, press Save and use to
select “Disk D” and press down to open the USB storage device.
3) Use
to select the desired storage position. The file can be stored under
the root directory or in a certain folder under the root directory of the USB
storage device.
Note: press NewFolder to create a new folder and for specific operation,
please refer to the instruction of “
To Create a New File or Folder”.
4) After the storage position is selected, press New File to create a new file
name using the pop-up keyboard, for detail operations, please refer to the
instruction of “
To Create a New File or Folder”. If the internal memory
has saved files in this type, use to select the file and Save and Delete
are illuminated, at this point, press Save to execute the saving operation,
the original file can be overwritten or be delected by pressing Delete. Use
to select and then press down to return to the previous
directory.
5) Press OK to execute the saving operation.
2. Load the specified type of file in the external USB storage device.
1) Press Storage  Storage to select “Traces” and then press Load and use
to select “Disk D” and then press down to open the local disk.
2) If the USB storage device has saved files in this type, use
to select the
desired file to load and press Load to load the file selected.
