Chapter 1 Quick Start RIGOL
DS1000Z User’s Guide
Front
Panel
Overview
Figure 0-9 Front Panel Overview
Table 0-1 Front Panel Description
No. Description No. Description
1 Menu 10 Power Key
2 LCD 11 USB HOST
3 Multi-function Knob 12 Function Setting Menu Softkeys
4 Function Menu Keys 13 Analog Channel Input Area
5 CLEAR 14 VERTICAL
6 AUTO 15 HORIZONTAL
7 RUN/STOP 16 TRIGGER
8
SINGLE
17 Probe Compensation Signal Output
Terminal/Ground Terminal
9 Help&Print -- --
10 11 12 13 14 15 16 17
3 4 5 6 7 8 9
1 2
