Rigol DS1000Z Series User Manual

RIGOL
DS1000Z User’s Guide
XI
DS1000Z Series Overview
DS1000Z is a high-performance digital oscilloscope developed on the basis of the
UltraVision technique. DS1000Z, featuring rather deep memory depth, ultra-wide
dynamic range, superb waveform capture rate and all-round trigger functions, is an
invaluable debug instrument in various fields (such as communication, cosmonautics,
national defense, embedded system, computer, research and education) and is the
one with the most complete functions and most outstanding specification among the
digital oscilloscopes with lower than 100 MHz bandwidth.
Main features:
 100 MHz and 70 MHz bandwidth.
 UltraVision technique.
 1 GSa/s maximum real-time sample rate.
 30,000 wfms/s (dots display) waveform capture rate.
 Real-time hardware waveform recording, waveform playback functions. Up to
60,000 frames of waveform can be recorded.
 24 Mpts maximum memory depth (option) and 12 Mpts standard memory
depth.
 Multi-degree gray scale display.
 Low noise, 1 mV/div to 10 V/div ultra-wide vertical dynamic range.
 7.0 inches, WVGA (800*480) 160,000 color TFT LCD, vivid picture, low power
consumption and long service life.
 Adjustable brightness of analog channel waveform.
 Auto setting of waveform display (AUTO).
 15 kinds of trigger functions including multiple protocol triggers.
 Standard parallel decoding and multiple serial decoding options.
 Auto measurements of 24 waveform parameters and measurement functions
with statistic.
 Precise delayed sweep function.
 Built-in FFT function.
 Pass/Fail test function.
 Multiple waveform math operation functions.
 Built-in dual-channel, 25 MHz signal source function (only available for
DS1000Z-S).
 Standard configuration interfaces: USB Device, USB Host, LAN and GPIB
(optional).
 Conform to LXI-C instrument standards. Enable quick, economic and efficient
