Chapter 8 Reference Waveform RIGOL
DS1000Z User’s Guide
8-3
To Adjust REF Waveform Display
To adjust the reference waveform specified in Current:
Press REF to enable the REF function. Then, press Offset and use to adjust the
vertical position of the reference waveform and press Scale and use to adjust
the vertical scale of the reference waveform.
To Save to Internal Memory
Press Save to save the waveform (screen region) in the specified source to internal
memory as reference waveform and display it on the screen. Note that this operation
only saves the reference waveform in the volatile memory and the waveform will be
cleared at power-off.
To Set the Color
DS1000Z series oscilloscope provides five colors (gray, green, light blue, magenta
and orange) to mark the reference waveforms of different channels in order to
distinguish them.
Press Current and use to select any of the reference channels (Ref1-Ref10)
enabled. Then, press Color to specify a different color for the reference waveform of
that channel. The corresponding icon at the left of the channel currently selected will
be filled with the specified color, for example,
.
To reset the REF waveform
Press Reset and the reference waveform returns to the position where the source
channel waveform is located when the Save operation was executed.
