Rockwell Automation Publication 1766-UM001O-EN-P - September 2021 245
Appendix F MicroLogix 1400 Distributed Network Protocol
DNP3 Device Attribute
Object
The Device Attribute object can be used to identify DNP3 Slave devices.
With the controller, some of the variations are written so that you can read or
write your own strings in your application.
The object group of the Device Attribute object is 0. The supported range of the
variation is 211…255.
The R/W property shows if the object is Read Only, Read, or Write. If the R/W
property is writable, the value which was written by DNP3 master device is
stored to non-volatile memory.
The object group of the Device Attribute is 0. The supported range of the
variation is 211…255.
Object Flags for Analog Output for Series B and Series C controllers
Bit Offset Name Description
0 ONLINE
0 when the controller is or was in Non-executing mode.
1 when the controller is or was in Executing mode and the configuration file does not exist.
May be 1 when the controller is in Executing mode and the configuration file exists.
1RESTART
0 when the controller is or was in Non-executing mode.
0 when the controller is or was in Executing mode and the configuration file does not exist.
May be 1 when the controller is in Executing mode and the configuration file exists.
2 COMM_LOST
3 REMOTE_FORCED
4LOCAL_FORCED
5 reserved
6 reserved
7 reserved
Object Group 0, Variations for Attribute Set 0
Variation Read /Write
Attribute
Data Type
Length in Bytes
(Series A)
Max Length in
Bytes (Series B
and Series C)
Description Value (Series A) Value (Series B)
211 Read Only VSTR 27 0 for DNP3
Identifier of support for user-
specific attributes
Returns the identifier for
user-specific attributes.
Rockwell Automation, Inc.,
1
Returns the identifier for
user-specific attributes.
"", NULL for DNP3.
212 Read Only UINT 4 2
Number of master-defined Data-
Set prototypes
00
213 Read Only UINT 4 2
Number of outstation-defined
Data-Set prototypes
0
The configured number in
the DNP3 Slave
Application Layer
Configuration file.
10, max
214 Read Only UINT 4 2
Number of master-defined Data-
Sets
00
215 Read Only UINT 4 2
Number of outstation-defined
Data-Sets
0
The configured number in
the DNP3 Slave
Application Layer
Configuration file.
10, max
216 Read Only UINT 4 2
Max number of binary outputs per
request
10 10
217 Read Only UINT 4 2 Local timing accuracy 10,000 in microseconds
218 Read Only UINT 4 2 Duration of timing accuracy 0 in seconds
219 Read Only INT 1 1 Support for analog output events 0 0
220 Read Only UINT 4 2 Max analog output index 256*3
221 Read Only UINT 4 2 Number of analog outputs 0…256*3
