Rockwell Automation Publication 1766-UM001O-EN-P - September 2021 75
Chapter 5
LCD and Keypad
The LCD and keypad are shown in Figure 56.
Figure 56 - Controller Part Identification
Topic Page
Operating Principles 76
I/O Status 80
Monitor User Defined Target Files 82
Mode Switch 94
User-defined LCD Screen 96
Configure Advanced Settings 97
Change Key In Mode 98
Communications Toggle Functionality 99
Ethernet Network Configuration 99
Trim Pots 107
View System Information 109
Save or Load Communication EEPROM 111
LCD setup 113
Protocol Configuration 115
LCD Password Setup 117
Table 12 - LCD and Keypad
Feature Description
10 LCD
5
LCD Screen Keypad
(ESC, OK, Up, Down, Left, and Right Buttons)
12 5 6 7
891011
13
12
43
ESC
OK
To Next Page
