Chapter 5 Dismantling components
148 SMSO-2-02.05- 15.07.03
5.4.12 Instant heater coffee
For safety information see the section entitled
“Safety Regulations”"
......... 01.04.2002
......... Serial no. 505123
Preparation
Disconnect supply connections
Dismantle the bean container
Dismantle the cup plate
Remove right hand casing
Dismantling
1. Disconnect the plug-in connection for the temperature
sensor
2. Loosen union nut at the beginning of the feed pipe
3. Loosen union nut at the hot water unit, lift off the hot
water pipe with valve (or valves) and put it aside.
4. Turn the boiler holder attachment screw outward
5. Remove the instant heater from the base
