Schaerer Ambiente 2 Service Manual

Chapter 2 General notes for service technicians
SMSO-2-02.02- 15.07.03 19
2.7 Service instructions - Refrigerator
2.7.1 Service intervals – Refrigerator / Cappuccinatore appliance (Index e, 30.06.2003)
Servicing must take place after every 45,000 – 50,000 cappuccino / milk servings, or every 12 months
No. 1-16 = check no. (see Section „Instructions on check numbers 1-16")
Description of part
Part
no.
After 45 – 50,000 cap-
puccino / milk servings
or after 12 months
After xx months or
max. counter reading
C R R
Non-return valve 063‘208
1
36 months
Rinsing water valves 063‘215
2 36 months
Rinsing valve – non-return valve pipes 063‘437
3
36 months
Seal to venting unit 063‘463
R
POM valve to venting unit 063‘578
4
36 months
Water cylinder 063‘573
5
Water cylinder O-Ring 063‘477
R
Water cylinder spring 063‘475
6
36 months
3- way valve 063‘206
2
36 months
Pipe between 3-way valve and water cylinder 063‘437
3
36 months
Steam valve battery 063‘467
7
36 months
2 way valve upper section 063‘247
R
Steam valves 063’715
R
Steam and milk tubes
valve battery - steam nozzles
061’108
061’109
3
Cappuccinatore complete 063‘115
8
36 months
Cappuccinatore seals 050‘415
R
Cappuccinatore steam nozzles 063‘479
9
36 months
Steam nozzles O-Ring 063‘495
R
Milk suction piece O-rings 063‘497
R
Milk suction set 063‘116
R
Blast valve T-piece 063‘580
10
Blast valve T-piece O rings 065‘632
R
0.35 mm dia. Baffle 061‘239
11
Expander 061’414
12 36 months
Expander O-rings 065‘644
R
Baffle for Cappuccino 063‘447
13
Milk cover 063‘445
13
Refrigerator 063‘572
14
C = check R = replace
