REPLACING THE FLUORESCENT LAMPS
13
1
Turn off the power.
2
Use a stool or steps when working on the top of
the cabinet. Remove the six screws from the top
of the billboard box.
Replacing the Billboard Box Florescent Lamp
FIG. 13a
3
Remove the FL box door from the top of the
billboard box.
FIG. 13b
4
Changetheorescentlamp.
FIG. 13c
SCREW (6)
M4x35, w/at & spring washers
FL BOX DOOR
FLORESCENT LAMP 32W
390-5251-32-01
