ASSEMBLY AND INSTALLATION
29
6
1
The billboard box has six shafts for attaching the
billboard.
Place a rubber washer onto each of these attach-
ment shafts.
The rubber washers, metal washers and low-head hexa-
gon
holescrewsarepartscreatedspecicallyforthis
product. If you lose them, they can be ordered from the
“contact address” in this manual or your supplier.
FIG. 6-7a Billboard
FIG. 6-7bFIG. 6-7c
2
Pass the attachment shafts through the at-
tachment holes in the billboard and attach the
billboard.
Ifitisdifculttomaketheattachment,loosen
the screws on the billboard box.
FIG. 6-7d
7 ATTACHING THE BILLBOARD
ATTACHMENT SHAFTS
RUBBER WASHER
SGS-1703
